VSHB-CD series pneumatic rubber roller huller
This rice huller machine is a rubber roller working rice processing machine. It is usually used for removing the paddy rice outside husk out from the paddy in the rice processing plant.
VSHB-CD series pneumatic rubber roller huller Technical parameter:
| Model | 10D | 10D*2 | 12D | 12D*2 |
|---|---|---|---|---|
| Rubber roller length(mm) | 254 | 254 | 300 | 300 |
| Rubber roller diameter(mm) | Φ255 | Φ255 | Φ255 | Φ255 |
| Capacity(t/h) | 3-6 | 6-12 | 4-7 | 8-14 |
| Power(kw) | 7.5 | 7.5*2 | 11 | 11*2 |
| Air volume(m³/h) | 3500-4000 | 7000-8000 | 4000-4500 | 8000-9000 |
| Weight(kg) | 750 | 1500 | 800 | 1600 |
| Size(mm) | 1595*700*2500 | 1595*1720*2500 | 1595*900*2500 | 1595*1870*2500 |
| Model | 14A | 14A*2 |
|---|---|---|
| Rubber roller length(mm) | 358 | 358 |
| Rubber roller diameter(mm) | Φ225 | Φ225 |
| Capacity(t/h) | 5-8 | 10-16 |
| Power(kw) | 11 | 11*2 |
| Air volume(m³/h) | 4500-5000 | 9000-10000 |
| Weight(kg) | 850 | 1700 |
| Size(mm) | 1700*1260*2350 | 1700*1910*2350 |
VSHB-CD series pneumatic rubber roller huller Product features:
The machine be used to husk for paddy and millet.the principle is depen on a pair of rubber rollers which have different linea speed which with opposite direction moving to squeeze and twist & tear grain for husking,
Adopting pneumatic system to adjust tighten roller pressure air cylinder control roller by automatic detection, and to push two roller* s touching and separating, mean while have grain passing, the roller touching, and without grain passing the roller separating. A vibrating feeder be matched make grain feed more evenly.
Hexagonal belt drive replace gear-box drive technology with a smaller noise and no oil leaking, more environment protection, the separating between the mixture of grain and husk through a suction blower by the different suspend speed
